High efficiency 1.0 ton 0.7Mpa 1.0Mpa 1.2Mpa low pressure wood chip steam boiler for machinery industry
Contact Person : Swet Lee
Phone Number : +8618736903078
WhatsApp : +8618736903078
Minimum Order Quantity : | 1 Set/Sets | Price : | Negotiation |
---|---|---|---|
Packaging Details : | The biomass steam generator is covered with a waterproof film and the transport package is a wooden box. | Delivery Time : | 15 work days |
Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram | Supply Ability : | 1500 Set/Sets Per Year |
Place of Origin: | HENAN CHINA | Brand Name: | SWET |
---|---|---|---|
Certification: | ISO 9001 | Model Number: | YDZ1.0-0.7-S |
Detail Information |
|||
Style: | Horizontal | Fuel: | Biomass Wood |
---|---|---|---|
Rated Evaporation: | 1000kg/h | Output: | Steam |
Working Pressure: | 0.7Mpa | ||
Highlight: | 1000kg/H Biomass Steam Boiler,Automatic Biomass Steam Boiler,Non Polluting Biomass Steam Boiler |
Product Description
1. The boiler safety is equipped with multi-level interlock protection: pressure switch protection (automatic shutdown and alarm above set pressure), low water level protection (water level in boiler body is lower than warning water level, automatic power off and alarm), safety valve protection (boiler) The pressure exceeds the working pressure, and the air pressure is automatically reduced.) Ensure that the boiler is safe under all working conditions and safe to get home.
2. Efficient energy-saving: biomass steam boiler using the most advanced micro-positive pressure combustion, a unique primary air heating, secondary air combustion configuration, making the combustion completely, the boiler body multi-return layout, compact structure, heating area sufficient, The furnace is very fast, 5 minutes pressure up to 0.7MPa
3. Biomass energy is a friendly, non-polluting, renewable,low carbon energy, and can save 50% cost compared with oil and gas .Use of biomass pellet fuel, convenient storage and transportation ,clean.
Rated evaporation |
Rated pressure |
Rated steam tempe rature |
Feed water temper ature |
Design thermal efficiency |
Water capacity |
Steam outlet |
water intake |
Drain valve |
Dimensions |
Shipping weight |
Full load biomass consumption |
||
L |
W |
H |
|||||||||||
Kg/h |
Mpa |
℃ |
℃ |
% |
L |
DN |
DN |
DN |
mm |
mm |
mm |
T |
kg/h |
1000 |
0.7 |
170 |
20 |
92% |
<29 |
50 | 25 | 25 | 2500 | 1700 | 2600 | 4.3 | 154 |
