100kg to 3000kg 300000Kcal/h to 2000000Kcal/h wood pellet hot water boiler
Contact Person : Swet Lee
Phone Number : +8618736903078
WhatsApp : +8618736903078
| Minimum Order Quantity : | 1 SET | Price : | Negotiation |
|---|---|---|---|
| Packaging Details : | Wooden boxes plus plastic paper packaging | Delivery Time : | 20work days |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram | Supply Ability : | 1200 Sets / Year |
| Place of Origin: | HENAN,CHINA | Brand Name: | SWET |
|---|---|---|---|
| Certification: | ISO9001 | Model Number: | LNS2 |
|
Detail Information |
|||
| Rated Capacity/t/h: | 2 | Working Pressure/MPA: | 1.25 |
|---|---|---|---|
| Steam Temperature/℃: | 193 | Feed Temperature/℃: | 20 |
| Testing Efficiency/%: | 95.81 | Gas Consumption/Nm3/h: | 163.72 |
| Highlight: | gas fired boiler,industrial water boiler |
||
Product Description
High thermal efficiency
100% corrugated furnace and spirally corrugated tube, can absorb flame heat effectively, thermal efficiency can be more than 96%.
Novel appearance
Boiler outer packing with novel appearance: color coated steel plate and hinged front and back smoke box.
PLC full automatic control system
PLC modular control system enhanced energy management system, offers significant advancements including many new individual monitoring points. With our optimized parameter setting ,the easy-to-use interface provides your facility with an intelligent boiler system to optimize energy and personnel management for increased productivity, efficiency and a reduced environmental impact.
| LNS series automatic gas (oil) steam energy saving boiler product selection form | ||||||||
| Model | Rated capacity | Working pressure | Steam temperature | Feed temperature | Testing efficiency | Diesel consumption | Gas consumption | Outline dimension |
| Unit | t/h | Mpa | ℃ | ℃ | ％ | Kg/h | Nm³/h | mm(H*W*L) |
| LNS20-1.25(1.6)-Q(Y) | 20 | 1.25/1.6 | 194/204 | 105 | 97.51 | 1276.63 | 1459 |
8870*3550 *3750 |
| LNS15-1.0(1.25)(1.6)-Q(Y) | 15 | 1.0/1.25/1.6 | 184/197/204 | 105 | 97.2 | 985.25 | 1126 |
7450*3520 *4090 |
| LNS10-1.25(1.6)-Q(Y) | 10 | 1.25/1.6 | 194/204 | 105 | 96.75 | 732.59 | 837.25 |
6370*2812 *3514 |
| LNS8-1.25(1.6)-Q(Y) | 8 | 1.25/1.6 | 194/204 | 105 | 96.7 | 576.84 | 659.25 |
6000*2920 *3403 |
| LNS6-1.25(1.6)-Q(Y) | 6 | 1.25/1.6 | 194/204 | 105 | 96.58 | 379.32 | 433.51 |
5470*2770 *3195 |
| LNS5-1.25(1.6)-Q(Y) | 5 | 1.25/1.6 | 194/204 | 20 | 96.48 | 358.16 | 409.33 |
5160*2410 *3015 |
| LNS4-1.0(1.25)(1.6)-Q(Y) | 4 | 1.0/1.25/1.6 | 184/197/204 | 20 | 96.3 | 292.45 | 334.23 |
4880*2710 *2600 |
| LNS3-1.0(1.25)(1.6)-Q(Y) | 3 | 1.0/1.25/1.6 | 184/197/204 | 20 | 95.99 | 214.48 | 245.12 |
4762*2447 *2469 |
| LNS2-1.0(1.25)-Q(Y) | 2 | 1.0/1.25 | 184/197/204 | 20 | 95.81 | 143.26 | 163.72 |
4030*2010 *2210 |
| Performance features: symmetrical furnace, uniform distribution, good cooling, sufficient combustion, long service life, stable output | ||||||||
