100kg to 3000kg 300000Kcal/h to 2000000Kcal/h wood pellet hot water boiler
Contact Person : Swet Lee
Phone Number : +8618736903078
WhatsApp : +8618736903078
| Minimum Order Quantity : | 1 Set/Sets | Price : | Negotiation |
|---|---|---|---|
| Packaging Details : | The boiler in nude package, but covered with water-proof covering, accessories in plywood case or tin case, this can be changed as your requirements | Delivery Time : | 25-30 work days |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram，Cash or on the basis of mutual agreement | Supply Ability : | 1500 Set/Sets Per Year |
| Place of Origin: | Henan China | Brand Name: | SWET |
|---|---|---|---|
| Certification: | ISO9001 | Model Number: | QXS(SZS)10.5-1.25-Y,Q-3006 |
|
Detail Information |
|||
| Nominal Working Pressure: | 1.0(1.25)(1.6) MPa | Leaving Water Temperature: | 115(130)(150) ℃ |
|---|---|---|---|
| Return Water Temperature: | 70(90)℃ | Efficiency: | 97 % |
| Model: | QXS(SZS)10.5-1.25-Y,Q-3006 | Keywords: | Hot Water Boiler |
| Color: | Customer Requirements | Rated Thermal Power: | 10.5 MW |
| Highlight: | gas fired boiler,industrial water boiler |
||
Product Description
Product description
1. SZS series of fuel (gas) hot water boiler for the classic D-type layout of the boiler.
2. The company's SZS series of fuel (gas) boiler is a typical D-type arrangement of double-drum longitudinal-type water tube boiler, according to the size of the boiler divided into fast-type and assembly type.
Product advantages
1. The compact structure of the boiler, covers an area of small, full of good flame.
2. Hot water boiler under the support method, the heat can be freely expanded.
3. The hot water boiler uses airtight inner fender, furnace body sealing, shape embossed suppressor plate, beautiful appearance.
4. The hot water boiler assembly and quick installation structure, effectively shorten the installation cycle.
Product parameters
| SZS water pipe type full automatic gas-fired hot water energy-saving boiler | |||||||
| Model | Rated thermal power | nominal working pressure | Leaving Water Temperature | return water temperature | efficiency | gas consumption | Overall dimensions of transportation |
| Unit | MW | MPa | ℃ | ℃ | % | Nm³/h | mm |
| QXS(SZS)58 | 58 | 1.25(1.6)(2.5) | 130(150) | 70(90) | 98.3 | 6196 | 15360*7570*8318 |
| QXS(SZS)48 | 48 | 1.25(1.6)(2.5) | 130(150) | 70(90) | 98.09 | 5048 | 15600*9500*7920 |
| QXS(SZS)29 | 29 | 1.25(1.6) | 130(150) | 70(90) | 97.8 | 3150 | 9685*6870*7180 |
| QXS(SZS)21 | 21 | 1.0(1.25)(1.6) | 115(130)(150) | 70(90) | 97.13 | 2328 | 10130*6170*6134 |
| QXS(SZS)14 | 14 | 1.0(1.25)(1.6) | 115(130)(150) | 70(90) | 97.02 | 1558 | 8120*3385*3750 |
| QXS(SZS)10.5 | 10.5 | 1.0(1.25)(1.6) | 115(130)(150) | 70(90) | 97 | 1136 | 7250*3682*3820 |
| QXS(SZS)7 | 7 | 0.7(1.0)(1.25) | 95(115)(130) | 70(90) | 96.87 | 754 | 6770*3210*3775 |
| QXS(SZS)7 | 7 | 1.25 | 115 | 70(90) | 95.76 | 763 | 6760*2780*3299 |
| QXS(SZS)5.6 | 5.6 | 0.7(1.0)(1.25) | 95(115)(130) | 70(90) | 95.57 | 619.2 | 6450*2956*3620 |
| QXS(SZS)4.2 | 4.2 | 0.7(1.0)(1.25) | 95(115)(130) | 70(90) | 95.36 | 456.7 | 5700*3105*3410 |
| QXS(SZS)2.5 | 2.5 | 0.7(1.0)(1.25) | 95(115) | 70(90) | 95.13 | 314 | 5160*2840*2930 |
| Performance features: symmetrical furnace, uniform distribution, good cooling, sufficient combustion, long service life, stable output | |||||||
FAQ
1. Q:When you ship my order?
A:Normally 7-30 days after receiving your payment.
2. Q:How to choose a boiler model?
A:Confirm the type (steam or hot water), capacity, pressure (or output temperature need) and fuel(coal, biomass, gas or oil) of the boiler, we will suggest a suitable model based on your usage
3. Q: What is the boiler warranty?
A: 2 years.
